| Intake pressure range (MPa) | 0.5~1.6 |
| Outlet pressure range (MPa) | 0.2~0.5 |
| Pressure regulation accuracy | 士5% |
| Rated flow range (Nm3/h) | 500~10000 |
| Intake pipe diameter (mm) | DN50~DN200 |
| Outlet pipe diameter (mm) | DN50~DN300 |
| Major equipment | AMCo, FISHER, RMG Regulators |
| Safety device | Overpressure cut-off, low pressure cut-off, safe release |
| Operating temperature | -45~45°C |
| Other function | Monitoring, metering, BOG gasification, bromine addition |
